EVOLVEO Thermal, smart wireless programmable thermostat

Modern control system for optimal comfort

The smart Thermal wireless thermostat brings a modern and intelligent solution for efficient temperature control in the home. Its advanced features and easy operation allow for optimal comfort and energy savings without complicated installation. The Thermal thermostat is designed to meet a variety of heating needs. Its programmable interface and support for different types of heating systems make it the ideal choice for boilers or underfloor heating.

Convenient control via smart app

The thermostat is fully compatible with the Smart Life, Tuya apps, which are freely downloadable for Android and iOS. The apps allow you to control the temperature in your home from anywhere using your smartphone or tablet. The app offers a wide range of features for full control of the thermostat, including the ability to set a target and check the current temperature, program time windows, set temperature limit protection, set a child lock to protect against unwanted changes to the temperature setting, set an open window function, calibrate the temperature sensor for accurate temperature measurement, set hysteresis to optimize heating operation, adjust the backlight brightness of the display to the user's preference, and reset to factory settings if needed.

Intuitive backlit touchscreen

With an elegant backlit touchscreen display and mirror effect, the Thermal thermostat offers not only a great look but also easy operation. Touch sensors allow easy temperature and function settings directly on the display.



A wide range of features for maximum comfort and energy savings

The Thermal thermostat offers a range of advanced features such as frost protection, child lock and open window detection. Thanks to these functions, the thermostat actively adapts to the ambient conditions and user behaviour. Frost protection ensures that the optimum temperature is maintained in freezing conditions, a child lock prevents unintentional changes to the temperature setting, and open window detection ensures that the thermostat automatically responds to room ventilation, helping to save energy.

Flexible programming and full control

With 7 days of programming per week and 4 time windows for each day, you get full control over the temperature in your home. The Thermal thermostat allows you to set different temperature profiles for different times of the day. The Thermal thermostat provides flexibility in the way it is powered - you can either power it with batteries or with a USB-C cable. It also offers a wide operating range of up to 100 meters in open spaces and up to 25 meters in enclosed spaces, ensuring reliable signal and temperature control even in large indoor environments.

Easy installation and compatibility

The Thermal thermostat is designed to be easy to install and compatible with various heating systems. With the supplied mounting components and installation instructions, the thermostat can be easily mounted on a wall or placed on a table as required. Its compatibility with Google Assistant, Amazon Alexa voice assistants allows you to control the temperature in your home with voice commands.

Technical Specifications:

• Suitable for connection to boiler, underfloor heating
• It consists of two parts:
• Receiver evaluating room temperature and communicating with the boiler/floor heating
• Transmitter enabling control and displaying the current status
• WiFi or Bluetooth connectivity to Tuya (Smart Life) app for iPhone and Android
• Touchscreen digital display with inverse backlight and mirror effect
• Setting the brightness of the display backlight when powered from USB
• Backlight intensity when powered by batteries: 40%
• Temperature sensor located on the outer surface of the transmitter for higher accuracy
• Programming for 7 days in a week (possibility of programming for days)
• 4 time windows for each day of the week
• Google Assistant and Amazon Alexa voice assistant support
• Child lock to deactivate display control
• Open window detection:
• automatic shutdown of heating in case of sudden temperature drop
• possibility to set the temperature drop limit to 2-4 °C
• option to set the drop time to 2-30 min.
• the ability to set the return from mode in 10-60 minutes
• Frost protection (automatic start of heating when the temperature drops below the set temperature limit in the range of 5-15 °C)
• The application allows:
• Setting the target and checking the current temperature
• Programming time windows
• Setting the frost protection temperature limit with the possibility of deactivating the function
• Child lock setting with deactivation option
• Setting the open window function including setting the temperature drop limit, drop time and return from the mode with the possibility of deactivating the function
• Calibration of the temperature sensor in the range -8 to +8 °C
• Hysteresis setting in the range of 0-3 °C
• Backlit brightness adjustment in the range of 0-100%
• Reset to factory settings
• Thermostat modes:
• Fully automatic programmable mode
• Manual mode for temporary setting to constant temperature
• Absence mode for temporary setting to economic reduced temperature
• Display on the transmitter shows: day of the week, time, instantaneous and target temperature, signal strength, battery status, heating indication, child lock indication, open window indication, absent mode indication
• LED indicators on the receiver to indicate active/inactive heating and power
• Radio communication frequency units: 868 MHz
• Operating range in open/enclosed space: 100/25 m
• The receiver can be installed in a wall-mounted junction box
• The transmitter can be installed on the wall or on a table
• Temperature setting in the range of 5-35 °C in 0.5 °C steps
• Hysteresis can be set in the range of 0-3 °C
• Measurement deviation ± 0.5 °C
• Receiver power supply: 230 V (wall wiring)
• Two transmitter power options:
• Power adapter with USB-C cable (included)
• 2 × AA pencil battery (not included)
• Nominal voltage of the power adapter: AC 100-240 V
• Nominal frequency of the power adapter: 50/60 Hz
• Output voltage and current of the power adapter: 5 V, 1 A
• Maximum ohmic load: 2500 W (250 V, 10 A)
• Storage: EEPROM
• Includes 4 screws and 4 screws for wall mounting in the junction box
• Length of USB-A to USB-C power cable: 1 m
• Transmitter dimensions: 125 × 98 × 23.5 mm
• Receiver dimensions: 90 × 90 × 26 mm
• Transmitter weight: 183 g
• Receiver weight: 109 g

Package contents:

• Receiver
• Transmitter
• Receiver frame for wall mounting
• Transmitter stand on table
• Power adapter
• Power cable
• 4 × screw (4 × 22 mm)
• 4 × screw (3.5 × 22 mm)
• Instruction manual (EN/DE/CZ/SK/HU/RO/IT/SLO)
